PDFL Series Compact Type
hiddenValue
- Description
- Parameter
- After-sales service
-
-
PDFL Series Specifications Table PTFL Series Specifications Table Model A B D L H 160C 160 262 60 217 206 250C 250 322 60 217 206 300C 300 372 60 217 206 350C 350 422 60 247 206 400C 400 472 60 247 206 450C 450 522 60 247 206 500C 500 572 60 247 206 600C 600 672 60 322 206 700C 700 772 60 322 206 800C 800 772 60 360 206 Technicallnformation XMax Guidingvalue ± 15-25mm U-Shaped PassingTension 200N- 80ON Guiding Speed 40- 60mm/sec Guiding Accuracy <±0.1mm（Decided by the material） Ambience Temperature 10- 50°c Air Humidity 0-90% Protection Class IP54 Operating Voltage 24VDC±5% Power Consumption 60VA
